FLOW, Q: max. 1060 US gpm

HEAD, H: max. 833 ft

LIQUID TEMPERATURE: -22 to 248°F

WORKING PRESSURE: max. 435 psi

KEY FEATURES AND BENEFITS

• Compact, inline design fits into small footprint

• Easy installation and operation with settings and internal connections done at factory

• Highly efficient design reduces energy consumption by up to half compared to fixed speed pumps

• Unique cartridge seal design can be replaced in minutes

• Spacercouplingallowsmotortobeleftinplaceduringsealreplacement

• Remote control/fieldbus monitoring and data collection

• Building management system compatible

• Userfriendlycontrollerinterfacewithadvancedfeaturesand functionality

• Laser welded stainless impellers promote class leading efficiency

• OptionalCRCool-TopTMallowspumptowithstandliquid temperatures of up to 356°F

• Integrated sensor available

• Four material options available, including cast iron, two grades of stainless steel, and all-titanium

• Thirteenflowsizes,capableofproducinguptoalmost725psipressure, and with a variety of shaft seals, rubber materials and supply voltages

• MAGdrive option available for demanding industrial applications where zero-leakage is required
